Name: Mobile Solar Lighting Tower
Brand: Tide Power
SKU: 390
Availability: InStock

Overview

The LM104LD-S Mobile Solar Lighting Tower is an integrated lighting solution designed for off-grid areas and emergency applications. It combines high-efficiency solar panels, a large-capacity gel battery bank, and high-brightness LED lamps on a trailer-mounted chassis. Its core advantage lies in fully solar-powered off-grid operation, significantly reducing fuel consumption and carbon emissions. The mast supports manual operation (standard) or optional hydraulic lifting, offering ease of use with high mobility and strong environmental adaptability, ensuring stable and safe lighting in demanding environments such as mining sites, airports, disaster relief zones, and outdoor engineering projects.

Benifits

•

Zero Emission & Sustainable Operation

Equipped with 5×380W high-efficiency solar panels, it operates on clean solar energy with no fuel consumption or exhaust emissions, resulting in extremely low operational costs.

•

Extended Lighting Duration

Powered by a 9.6kWh high-capacity battery bank, it provides up to 21 hours of continuous lighting on a full charge, meeting overnight operational requirements.

•

High Brightness & Wide Coverage

The 4×100W LED lamps deliver a total luminous flux of 68,000 lumens, covering 2,000 square meters at 5 lux, ensuring broad and uniform illumination.

•

Flexible Deployment

The trailer-mounted design allows for rapid relocation with a maximum towing speed of 60 km/h. The mast, available with manual or hydraulic lifting, reaches a maximum height of 7.5 meters and offers 359° rotation, eliminating blind spots.

•

Robust & Durable

Built with a weatherproof enclosure and key components rated IP67, it withstands harsh conditions such as rain, snow, and sandstorms, with a design life of up to 10 years.

Inquiry / Message

FAQ

Can the LM104LD-S operate during consecutive cloudy or rainy days?

Yes. The high-capacity battery bank provides up to 21 hours of continuous lighting on a full charge. In case of extended cloudy or rainy conditions, it is recommended to manage power usage via the optional intelligent control system or use the external charging interface to supplement power.

What are the mast lifting options? How to choose?

The standard configuration features a manual mast lifting system, which is simple to operate and low-cost to maintain. An optional hydraulic lifting system is available for one-touch operation, offering greater convenience and ease of use. Customers can choose based on usage frequency and operational requirements.

Is it easy to extend and retract the solar panels?

The solar panels feature a manual extension design that can be operated by a single person. The total extended area is 9.7 square meters, with a stable structure. When folded, the panels integrate with the unit for easy transport and relocation.

Is the unit convenient for transport and relocation?

Very convenient. The unit is built on a trailer chassis with a maximum towing speed of 60 km/h, complying with road transport standards. With a total weight of 1112 kg and a compact design, it can be towed by a pickup truck or light-duty vehicle.

What is the product's service life and warranty policy?

The battery has a design life of 10 years, and the overall structure along with LED lamps are made of high-quality weather-resistant materials. The standard warranty period is 2 years, with extended warranty options available. Please contact the sales team for details.
